LTC1261LIS8-4.5#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LTC1261 Tape & Reel (TR) Matte Tin (Sn) Active DC to DC switching regulator 5V 3.899mm 20mA 650kHz
PDF
/
Inventory: 5600
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.899mm
Length 4.9025mm
Technical
Switcher Configuration DOUBLER INVERTER
Synchronous Rectifier No
Frequency - Switching 650kHz
Topology Charge Pump
Voltage - Output (Min/Fixed) -4.5V
Current - Output 20mA
Output Configuration Negative
Analog IC - Other Type SWITCHED CAPACITOR REGULATOR
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Output Type Fixed
Output Voltage -4.5V
Voltage - Input (Max) 5.25V
Number of Outputs 1
Function Step-Up/Step-Down
JESD-30 Code R-PDSO-G8
Base Part Number LTC1261
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Other Analog ICs
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
