LT3973EDD#PBF
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LT3973 Tube Matte Tin (Sn) PRODUCTION (Last Updated: 1week ago) DC to DC switching regulator 24V 3mm 750mA 195kHz~2.15MHz
PDF
/
Buying Options
Total Price: USD $7
Unit Price: USD $7.0048
≥1 USD $7.0048
≥10 USD $6.32544
≥100 USD $6.030816
≥500 USD $5.236651
≥1000 USD $5.001286
≥3000 USD $4.559984
Inventory: 349
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 week ago)
Physical
Mounting Type Surface Mount
Package / Case 10-WFDFN Exposed Pad
Surface Mount YES
Number of Pins 10
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tube
Published 2010
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Switching Regulator or Controllers
Technology BIPOLAR
Terminal Position DUAL
Terminal Pitch 0.5mm
Base Part Number LT3973
Function Step-Down
Number of Outputs 1
Voltage - Input (Max) 42V
Output Voltage 24V
Output Type Adjustable
Voltage - Input (Min) 4.2V
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING REGULATOR
Output Configuration Positive
Current - Output 750mA
Voltage - Output (Min/Fixed) 1.21V
Topology Buck
Control Mode CURRENT-MODE
Frequency - Switching 195kHz~2.15MHz
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier No
Dimensions
Height Seated (Max) 0.8mm
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
