LT3693IDD#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LT3693 Tape & Reel (TR) Matte Tin (Sn) Active DC to DC switching regulator 10V 3mm 3.5A 230kHz~2.45MHz
PDF
/
Buying Options
Total Price: USD $10.29
Unit Price: USD $10.2872
≥1 USD $10.2872
≥10 USD $9.45208
≥100 USD $9.060128
≥500 USD $7.982568
≥1000 USD $7.59081
≥3000 USD $7.101072
Inventory: 1133
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 10-WFDFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Switching Regulator or Controllers
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LT3693
Function Step-Down
Number of Outputs 1
Voltage - Input (Max) 36V
Output Type Adjustable
Voltage - Input (Min) 3.6V
Input Voltage-Nom 10V
Analog IC - Other Type SWITCHING REGULATOR
Output Configuration Positive
Current - Output 3.5A
Voltage - Output (Min/Fixed) 0.79V
Topology Buck
Control Mode CURRENT-MODE
Frequency - Switching 230kHz~2.45MHz
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier No
Voltage - Output (Max) 30V
Dimensions
Height Seated (Max) 0.8mm
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
