LT3470HTS8#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-8 Thin, TSOT-23-8
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LT3470 Tape & Reel (TR) Matte Tin (Sn) PRODUCTION (Last Updated: 3weeks ago) DC to DC switching regulator 10V 2.9mm 200mA -40C~150C TJ
PDF
/
Buying Options
Total Price: USD $8.54
Unit Price: USD $8.5448
≥1 USD $8.5448
≥10 USD $7.72024
≥100 USD $7.361024
≥500 USD $6.391528
≥1000 USD $6.104278
≥3000 USD $5.565666
Inventory: 1192
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Physical
Mounting Type Surface Mount
Package / Case SOT-23-8 Thin, TSOT-23-8
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2011
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Switching Regulator or Controllers
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LT3470
Function Step-Down
Number of Outputs 1
Voltage - Input (Max) 40V
Output Voltage 16V
Output Type Adjustable
Voltage - Input (Min) 4V
Input Voltage-Nom 10V
Analog IC - Other Type SWITCHING REGULATOR
Output Configuration Positive
Current - Output 200mA
Voltage - Output (Min/Fixed) 1.25V
Topology Buck
Control Mode CURRENT-MODE
Control Technique HYSTERETIC CURRENT MODE
Synchronous Rectifier No
Dimensions
Length 2.9mm
Compliance
RoHS Status ROHS3 Compliant
