LT1931AES5#TRMPBF
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-5 Thin, TSOT-23-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LT1931 Cut Tape (CT) Matte Tin (Sn) Active DC to DC switching regulator 3V 2.9mm 1A 2.2MHz
PDF
/
Buying Options
Total Price: USD $5.41
Unit Price: USD $5.412
≥1 USD $5.412
≥10 USD $4.89192
≥100 USD $4.664352
≥500 USD $4.050112
≥1000 USD $3.868058
Inventory: 44
Minimum: 1
-
+
Technical Details
Technical
Voltage - Output (Min/Fixed) -1.255V
Topology Cuk
Control Mode CURRENT-MODE
Frequency - Switching 2.2MHz
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier No
Switcher Configuration BUCK-BOOST
Voltage - Output (Max) -34V
Current - Output 1A
Output Configuration Negative
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 3V
Voltage - Input (Min) 2.45V
Output Type Adjustable
Voltage - Input (Max) 16V
Number of Outputs 1
Function Step-Up/Step-Down
JESD-30 Code R-PDSO-G5
Base Part Number LT1931
Terminal Pitch 0.95mm
Peak Reflow Temperature (Cel) 250
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Switching Regulator or Controllers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2005
Packaging Cut Tape (CT)
Operating Temperature 0°C~70°C TA
Dimensions
Length 2.9mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Surface Mount YES
Package / Case SOT-23-5 Thin, TSOT-23-5
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
