UCC3580DTR-3
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
IC REG CTRLR FWRD CONV 16SOIC
PDF
/
Buying Options
Total Price: USD $1.52
Unit Price: USD $1.52475
≥1 USD $1.52475
≥10 USD $1.25115
≥100 USD $1.2122
≥500 USD $1.1723
≥1000 USD $1.13335
Inventory: 3287
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 9.9mm
Height 1.75mm
Technical
Output Phases 1
Duty Cycle (Max) 66%
Max Duty Cycle 69 %
Switcher Configuration BUCK-BOOST
Fall Time (Typ) 20 ns
Synchronous Rectifier No
Supply Current-Max (Isup) 3.5mA
Rise Time 40ns
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 400kHz
Control Mode VOLTAGE-MODE
Topology Forward Converter
Control Features Enable, Ramp, Soft Start
Voltage - Supply (Vcc/Vdd) 8.5V~16V
Output Current 100mA
Output Configuration Positive or Negative
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 12V
Output Type Transistor Driver
Output Voltage 400mV
Number of Outputs 2
Function Step-Up/Step-Down
Base Part Number UCC3580
Frequency 1MHz
Supply Voltage 12V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Switching Regulator or Controllers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Weight 141.690917mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
