UCC28230DRNR
RoHS
RoHS compliant
RoHS compliantPackage 12-UFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
UCC28230 Full-Bridge Half-Bridge Push-Pull Tape & Reel (TR) e4 DC to DC switching controller 0.2A 16.300976mg 3.3V 100kHz~550kHz
PDF
/
Buying Options
Total Price: USD $2.17
Unit Price: USD $2.16505
≥1 USD $2.16505
≥10 USD $1.7765
≥100 USD $1.72045
≥500 USD $1.66535
≥1000 USD $1.61025
Inventory: 1177
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 12-UFDFN Exposed Pad
Surface Mount YES
Number of Pins 12
Weight 16.300976mg
Technical
Operating Temperature -55°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Terminal Finish NICKEL PALLADIUM GOLD
Subcategory Switching Regulator or Controllers
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Supply Voltage 12V
Terminal Pitch 0.5mm
Base Part Number UCC28230
Function Step-Up/Step-Down
Number of Outputs 4
Output Voltage 3.3V
Output Type Transistor Driver
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Voltage - Supply (Vcc/Vdd) 7V~17V
Control Features Frequency Control, Soft Start
Input Voltage (Min) 7V
Topology Full-Bridge, Half-Bridge, Push-Pull
Control Mode CURRENT-MODE
Output Current-Max 0.2A
Frequency - Switching 100kHz~550kHz
Control Technique PULSE WIDTH MODULATION
Supply Current-Max (Isup) 2.5mA
Synchronous Rectifier No
Max Frequency 1MHz
Max Duty Cycle 100 %
Duty Cycle 100 %
Output Phases 1
Dimensions
Height 600μm
Length 2mm
Width 3mm
Thickness 550μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
