UCC2585M
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
VOLTAGE-MODE BICMOS DUAL Surface Mount DC-DC Controller IC -40C~85C TA 500kHz 900mV 4.9mm
PDF
/
Buying Options
Total Price: USD $3.02
Unit Price: USD $3.021872
≥1 USD $3.021872
≥10 USD $2.850823
≥100 USD $2.689461
≥500 USD $2.537226
≥1000 USD $2.393607
Inventory: 1595
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Clock Sync No
Duty Cycle (Max) 100%
Max Frequency 485kHz
Switcher Configuration PUSH-PULL
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 6.3V
Frequency - Switching 500kHz
Output Current-Max 1A
Control Mode VOLTAGE-MODE
Topology Buck
Input Voltage (Min) 3V
Control Features Current Limit, Enable, Frequency Control, Soft Start
Voltage - Supply (Vcc/Vdd) 3V~5.5V
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 3.3V
Operating Supply Voltage 5V
Output Type Transistor Driver
Output Voltage 900mV
Number of Outputs 1
Function Step-Down
Base Part Number UCC2585
Terminal Pitch 0.635mm
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Switching Regulator or Controllers
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 16
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
