UCC25630-1DDBT
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width), 14 Leads
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
UCC25630 Half-Bridge Tape & Reel (TR) e4 DC to DC switching controller 1.75mm 26V 35kHz~1MHz -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $3.87
Unit Price: USD $3.872
≥1 USD $3.872
≥10 USD $3.47512
≥100 USD $3.285568
≥500 USD $2.847592
Inventory: 557
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.58mm
Width 3.9mm
Length 9mm
Height 1.75mm
Technical
Duty Cycle (Max) 50%
Synchronous Rectifier No
Control Technique HYSTERETIC CURRENT MODE
Input Voltage (Max) 26V
Frequency - Switching 35kHz~1MHz
Topology Half-Bridge
Control Features Hybrid Hysteretic Control (HHC)
Voltage - Supply (Vcc/Vdd) 13V~26V
Output Configuration Positive, Isolation Capable
Analog IC - Other Type POWER FACTOR CONTROLLER
Input Voltage-Nom 15V
Output Type Transistor Driver
Number of Outputs 1
Base Part Number UCC25630
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 14
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width), 14 Leads
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
