UC3886N
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
CURRENT-MODE BIPOLAR DUAL Through Hole DC-DC Controller IC 150ns 0C~70C TA Up to 300kHz 10.3V
PDF
/
Buying Options
Total Price: USD $3.94
Unit Price: USD $3.9424
≥1 USD $3.9424
Inventory: 174
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Height Seated (Max) 5.33mm
Technical
Max Duty Cycle 90 %
Fall Time (Typ) 150 ns
Synchronous Rectifier No
Rise Time 150ns
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 20V
Frequency - Switching Up to 300kHz
Control Mode CURRENT-MODE
Topology Buck
Control Features Enable, Frequency Control
Voltage - Supply (Vcc/Vdd) 10.3V~20V
Output Current 200mA
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 12V
Output Type Transistor Driver
Output Voltage 10.3V
Number of Outputs 1
Function Step-Down
Base Part Number UC3886
Frequency 400kHz
Terminal Pitch 2.54mm
Terminal Position DUAL
Technology BIPOLAR
Subcategory Switching Regulator or Controllers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Weight 1.053808g
Number of Pins 16
Surface Mount NO
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
