UC3573NG4
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
VOLTAGE-MODE BIPOLAR DUAL Through Hole DC-DC Controller IC 0C~70C TA 100kHz 30V 528.605208mg
PDF
/
Buying Options
Total Price: USD $1
Unit Price: USD $1.001475
≥1 USD $1.001475
≥10 USD $0.944788
≥100 USD $0.891314
≥500 USD $0.84086
≥1000 USD $0.793265
Inventory: 1523
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Weight 528.605208mg
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Switching Regulator or Controllers
Technology BIPOLAR
Terminal Position DUAL
Terminal Pitch 2.54mm
Frequency 100kHz
Base Part Number UC3573
Function Step-Down
Number of Outputs 1
Output Voltage 30V
Output Type Transistor Driver
Max Output Current 700mA
Input Voltage-Nom 5V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Output Current 500mA
Voltage - Supply (Vcc/Vdd) 4.75V~30V
Control Features Current Limit, Ramp
Topology Buck
Control Mode VOLTAGE-MODE
Max Input Voltage 35V
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier No
Switcher Configuration SINGLE
Duty Cycle (Max) 92%
Dimensions
Height 4.57mm
Length 9.81mm
Width 6.35mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
