UC3526ADW
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
UC3526 Buck Boost Flyback Forward Converter Full-Bridge Half-Bridge Push-Pull Tube e4 DC to DC switching controller 100ns 200mA 2.65mm 13V
PDF
/
Buying Options
Total Price: USD $3.06
Unit Price: USD $3.0624
≥1 USD $3.0624
≥10 USD $2.75
≥100 USD $2.59974
≥500 USD $2.25309
≥1000 USD $2.137555
≥3000 USD $1.91803
Inventory: 844
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Surface Mount
Package / Case 18-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 18
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 18
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Frequency 650kHz
Base Part Number UC3526
Function Step-Up, Step-Down, Step-Up/Step-Down
Number of Outputs 2
Output Voltage 13V
Output Type Transistor Driver
Input Voltage-Nom 15V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Output Current 200mA
Voltage - Supply (Vcc/Vdd) 7V~35V
Quiescent Current 14mA
Control Features Enable, Frequency Control, Reset, Soft Start
Topology Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Control Mode VOLTAGE-MODE
Frequency - Switching 1Hz~600kHz
Control Technique PULSE WIDTH MODULATION
Rise Time 300 ns
Synchronous Rectifier Yes
Fall Time (Typ) 100 ns
Nominal Input Voltage 35V
Max Duty Cycle 50 %
Duty Cycle (Max) 49%
Output Phases 1
Dimensions
Height 2.65mm
Length 11.5mm
Width 7.5mm
Thickness 2.35mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
