UC2863N
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
VOLTAGE-MODE BIPOLAR DUAL Through Hole DC-DC Controller IC 25ns -40C~85C TA 50kHz~500kHz 1.7V
PDF
/
Buying Options
Total Price: USD $3.61
Unit Price: USD $3.608
≥1 USD $3.608
Inventory: 660
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 5.08mm
Technical
Output Phases 1
Duty Cycle (Max) 100%
Max Duty Cycle 50 %
Fall Time (Typ) 25 ns
Synchronous Rectifier No
Rise Time 25ns
Control Technique RESONANT CONTROL
Frequency - Switching 50kHz~500kHz
Control Mode VOLTAGE-MODE
Topology Full-Bridge, Half-Bridge, Push-Pull
Input Voltage (Min) 8V
Control Features Soft Start
Voltage - Supply (Vcc/Vdd) 7V~22V
Output Current 200mA
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 12V
Output Type Transistor Driver
Output Voltage 1.7V
Number of Outputs 2
Function Step-Up/Step-Down
Base Part Number UC2863
Frequency 450kHz
Terminal Position DUAL
Technology BIPOLAR
Subcategory Switching Regulator or Controllers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Weight 1.053808g
Number of Pins 16
Surface Mount NO
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
