UC2842DW
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
UC2842 Boost Buck Buck-Boost Flyback Forward Tube Positive DC to DC switching controller 50ns 200mA 2.65mm 13.5V
PDF
/
Buying Options
Total Price: USD $0.91
Unit Price: USD $0.9064
≥1 USD $0.9064
Inventory: 1434
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Duty Cycle (Max) 97%
Max Duty Cycle 100 %
Switcher Configuration SINGLE
Nominal Input Voltage 25V
Fall Time (Typ) 50 ns
Synchronous Rectifier No
Rise Time 50ns
Control Technique PULSE WIDTH MODULATION
Frequency - Switching Up to 500kHz
Control Mode CURRENT-MODE
Topology Boost, Buck, Buck-Boost, Flyback, Forward
Control Features Frequency Control
Voltage - Supply (Vcc/Vdd) 12V~28V
Output Current 200mA
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 15V
Output Type Transistor Driver
Output Voltage 13.5V
Number of Outputs 1
Function Step-Up, Step-Down, Step-Up/Step-Down
Base Part Number UC2842
Frequency 450kHz
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Switching Regulator or Controllers
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
