UC2825Q
RoHS
RoHS compliant
RoHS compliantPackage 20-LCC (J-Lead)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
VOLTAGE-MODE BICMOS QUAD Surface Mount DC-DC Controller IC 30ns -40C~85C TA 340kHz~460kHz 13V
PDF
/
Buying Options
Total Price: USD $2.36
Unit Price: USD $2.3584
≥1 USD $2.3584
Inventory: 179
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-LCC (J-Lead)
Surface Mount YES
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature CAN ALSO BE CONFIGURED IN CURRENT MODE
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 260
Frequency 1MHz
Base Part Number UC2825
Function Step-Up, Step-Up/Step-Down
Number of Outputs 2
Output Voltage 13V
Output Type Transistor Driver
Input Voltage-Nom 15V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Output Current 200mA
Voltage - Supply (Vcc/Vdd) 8.4V~30V
Control Features Current Limit, Enable, Frequency Control, Ramp, Soft Start
Input Voltage (Min) 8.8V
Topology Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Control Mode VOLTAGE-MODE
Frequency - Switching 340kHz~460kHz
Input Voltage (Max) 30V
Control Technique PULSE WIDTH MODULATION
Rise Time 30ns
Synchronous Rectifier No
Fall Time (Typ) 30 ns
Max Duty Cycle 80 %
Output Phases 1
Dimensions
Height Seated (Max) 4.57mm
Length 8.965mm
Width 8.965mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
