UC2825DWTRG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
Boost Flyback Push-Pull Tape & Reel (TR) e4 CAN ALSO BE CONFIGURED IN CURRENT MODE DC to DC switching controller 30ns 200mA 473.692182mg 5.1V
PDF
/
Buying Options
Total Price: USD $13.42
Unit Price: USD $13.42445
≥1 USD $13.42445
≥10 USD $11.01525
≥100 USD $10.6704
≥500 USD $10.3265
≥1000 USD $9.9826
Inventory: 6319
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7.5mm
Length 10.3mm
Technical
Duty Cycle (Max) 80 %
Max Duty Cycle 50 %
Fall Time (Typ) 30 ns
Rise Time 30ns
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 1MHz
Control Mode VOLTAGE-MODE
Topology Boost, Flyback, Push-Pull
Input Voltage (Min) 8.8V
Voltage - Output 13V
Frequency (Max) 1MHz
Current - Output 200mA
Analog IC - Other Type SWITCHING CONTROLLER
Max Supply Voltage 30V
Temperature Grade INDUSTRIAL
Input Voltage-Nom 15V
Output Voltage 5.1V
Number of Outputs 2
Pin Count 16
Frequency 1MHz
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Switching Regulator or Controllers
Additional Feature CAN ALSO BE CONFIGURED IN CURRENT MODE
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 473.692182mg
Number of Pins 16
Surface Mount YES
Package / Case SOIC
