UC28023DWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
UC28023 Boost Flyback Forward Converter Full-Bridge Half-Bridge Push-Pull Tape & Reel (TR) e4 DC to DC switching controller 60ns 200mA 473.692182mg 13V
PDF
/
Buying Options
Total Price: USD $2.78
Unit Price: USD $2.7808
≥1 USD $2.7808
≥10 USD $2.49568
≥100 USD $2.359808
≥500 USD $2.04512
≥1000 USD $1.940259
≥3000 USD $1.740974
Inventory: 817
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 16
Weight 473.692182mg
Technical
Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature CAN ALSO BE CONFIGURED IN PEAK CURRENT OR AVERAGE CURRENT MODE
Subcategory Switching Regulator or Controllers
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Frequency 1MHz
Base Part Number UC28023
Function Step-Up, Step-Up/Step-Down
Number of Outputs 1
Output Voltage 13V
Output Type Transistor Driver
Input Voltage-Nom 15V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Output Current 200mA
Voltage - Supply (Vcc/Vdd) 9V~30V
Control Features Current Limit, Enable, Frequency Control, Ramp, Soft Start
Topology Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Control Mode VOLTAGE-MODE
Frequency - Switching 340kHz~460kHz
Control Technique PULSE WIDTH MODULATION
Rise Time 60 ns
Synchronous Rectifier Yes
Fall Time (Typ) 60 ns
Nominal Input Voltage 30V
Max Duty Cycle 100 %
Duty Cycle (Max) 90%
Clock Sync No
Dimensions
Height 2.65mm
Length 10.3mm
Width 7.5mm
Thickness 2.35mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
