TPS53015DGSR
RoHS
RoHS compliant
RoHS compliantPackage 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
TPS53015 Buck Tape & Reel (TR) D-CAP2? Eco-Mode? DC to DC switching controller 0.424A 1.07mm 7V 500kHz
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3816
≥1 USD $1.3816
≥10 USD $1.232
≥100 USD $1.169696
≥500 USD $0.960784
≥1000 USD $0.898128
≥3000 USD $0.79369
Inventory: 1573
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Number of Pins 10
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series D-CAP2?, Eco-Mode?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 10
ECCN Code EAR99
Additional Feature ALSO OPERATES IN ADJUSTABLE MODE FROM 0.77 TO 7V
Subcategory Switching Regulator or Controllers
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 12V
Terminal Pitch 0.5mm
Base Part Number TPS53015
Function Step-Down
Number of Outputs 1
Output Voltage 7V
Output Type Transistor Driver
Operating Supply Voltage 28V
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Voltage - Supply (Vcc/Vdd) 4.5V~28V
Quiescent Current 660μA
Control Features Enable, Power Good
Input Voltage (Min) 4.5V
Topology Buck
Control Mode VOLTAGE-MODE
Output Current-Max 0.424A
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Max Frequency 500kHz
Clock Sync No
Duty Cycle 83 %
Dimensions
Height 1.07mm
Length 3mm
Width 3mm
Thickness 1.02mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
