TPS51113DRCT
RoHS
RoHS compliant
RoHS compliantPackage 10-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
TPS51113 Buck Cut Tape (CT) e4 DC to DC switching controller 10A 1.5A 26.109911mg 35V
PDF
/
Buying Options
Total Price: USD $2.9
Unit Price: USD $2.8952
≥1 USD $2.8952
≥10 USD $2.60392
≥100 USD $2.461888
≥500 USD $2.13356
Inventory: 1154
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mounting Type Surface Mount
Package / Case 10-VFDFN Exposed Pad
Surface Mount YES
Number of Pins 10
Weight 26.109911mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Cut Tape (CT)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 10
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.5mm
Frequency 300kHz
Base Part Number TPS51113
Function Step-Down
Number of Outputs 1
Output Voltage 35V
Output Type Transistor Driver
Max Output Current 10A
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Output Current 1.5A
Voltage - Supply (Vcc/Vdd) 4.5V~13.2V
Output Power 2.61W
Control Features Enable, Power Good
Accuracy 1 %
Max Output Voltage 35V
Topology Buck
Min Input Voltage 4.5V
Control Mode VOLTAGE-MODE
Max Input Voltage 13.2V
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Min Output Voltage -3V
Switcher Configuration PUSH-PULL
Duty Cycle (Max) 72%
Clock Sync No
Dimensions
Height 1mm
Length 3mm
Width 3mm
Thickness 900μm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
