TPS40100RGER
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
TPS40100 Buck Tape & Reel (TR) e4 DC to DC switching controller 20A 20A 45.387587mg 5.5V
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.7974
≥1 USD $1.7974
≥10 USD $1.47535
≥100 USD $1.4288
≥500 USD $1.3832
≥1000 USD $1.33665
Inventory: 1720
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 880μm
Width 4mm
Length 4mm
Height 1mm
Technical
Duty Cycle 85 %
Max Frequency 600kHz
Switcher Configuration PUSH-PULL
Min Output Voltage 700mV
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 18V
Frequency - Switching 100kHz~600kHz
Control Mode CURRENT-MODE
Min Input Voltage 4.5V
Topology Buck
Max Output Voltage 5.5V
Control Features Current Limit, Frequency Control, Power Good, Soft Start, Tracking
Quiescent Current 1.8mA
Voltage - Supply (Vcc/Vdd) 4.5V~18V
Output Current 20A
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 12V
Operating Supply Voltage 18V
Max Output Current 20A
Output Type Transistor Driver
Output Voltage 5.5V
Qualification Status Not Qualified
Number of Outputs 1
Function Step-Down
Base Part Number TPS40100
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Subcategory Switching Regulator or Controllers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 45.387587mg
Number of Pins 24
Surface Mount YES
Package / Case 24-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
Alternative Model
