TPS40055MPWPREP
RoHS
RoHS compliant
RoHS compliantPackage 16-PowerTSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
TPS40055 Buck Tape & Reel (TR) e4 DC to DC switching controller 1.5mA 20A 62.709145mg 35V
PDF
/
Buying Options
Total Price: USD $8.97
Unit Price: USD $8.9672
≥1 USD $8.9672
≥10 USD $8.10392
≥100 USD $7.727104
≥500 USD $6.70956
≥1000 USD $6.407984
≥3000 USD $5.842566
Inventory: 1195
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 5mm
Height 1.2mm
Technical
Duty Cycle (Max) 94%
Max Frequency 1MHz
Switcher Configuration PUSH-PULL
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 40V
Frequency - Switching Up to 1MHz
Control Mode VOLTAGE-MODE
Topology Buck
Control Features Current Limit, Enable, Frequency Control, Soft Start
Quiescent Current 1.5mA
Voltage - Supply (Vcc/Vdd) 8V~40V
Output Current 20A
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 24V
Operating Supply Voltage 40V
Output Type Transistor Driver
Output Voltage 35V
Number of Outputs 1
Function Step-Down
Base Part Number TPS40055
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C TA
Physical
Weight 62.709145mg
Number of Pins 16
Package / Case 16-PowerTSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
Alternative Model
