TL594CDR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
TL594 Buck Boost Flyback Forward Converter Full-Bridge Half-Bridge Push-Pull Cut Tape (CT) e3 DC to DC switching controller 45ns 200mA 141.690917mg 40V
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.71544
≥100 USD $0.67936
≥500 USD $0.558096
≥1000 USD $0.521664
≥3000 USD $0.461014
Inventory: 1402
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 16
Weight 141.690917mg
Technical
Operating Temperature 0°C~70°C TA
Packaging Cut Tape (CT)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Switching Regulator or Controllers
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 15V
Frequency 300kHz
Base Part Number TL594
Function Step-Up, Step-Down, Step-Up/Step-Down
Number of Outputs 2
Output Voltage 40V
Output Type Transistor Driver
Input Voltage-Nom 15V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Output Current 200mA
Voltage - Supply (Vcc/Vdd) 7V~40V
Quiescent Current 12.4mA
Control Features Dead Time Control, Frequency Control
Input Voltage (Min) 7V
Topology Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Control Mode VOLTAGE-MODE
Frequency - Switching 1kHz~300kHz
Control Technique PULSE WIDTH MODULATION
Rise Time 200 ns
Synchronous Rectifier No
Fall Time (Typ) 45 ns
Max Duty Cycle 45 %
Duty Cycle (Max) 97%
Output Phases 1
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
