LM5176QPWPRQ1
RoHS
RoHS compliant
RoHS compliantPackage 28-PowerTSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
CURRENT-MODE DUAL Surface Mount RoHS Compliant DC to DC switching controller -40C~125C TJ 100kHz~600kHz 55V 9.7mm
PDF
/
Buying Options
Total Price: USD $7.25
Unit Price: USD $7.2512
≥1 USD $7.2512
≥10 USD $6.54896
≥100 USD $6.244128
≥500 USD $5.421768
≥1000 USD $5.178061
≥3000 USD $4.721165
Inventory: 1946
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 4.4mm
Length 9.7mm
Technical
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 55V
Frequency - Switching 100kHz~600kHz
Control Mode CURRENT-MODE
Topology Buck-Boost
Input Voltage (Min) 4.2V
Control Features Current Limit, Enable, Frequency Control, Power Good, Soft Start
Voltage - Supply (Vcc/Vdd) 4.2V~55V
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 24V
Output Type Transistor Driver
Number of Outputs 1
Function Step-Up/Step-Down
JESD-30 Code R-PDSO-G28
Base Part Number LM5176
Reach Compliance Code compliant
Terminal Pitch 0.65mm
Terminal Form GULL WING
Terminal Position DUAL
Additional Feature ADJUSTABLE VOLTAGE FROM 0.8 TO 55V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Surface Mount YES
Package / Case 28-PowerTSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
