LM5117PSQE/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 24-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LM5117 Buck Tape & Reel (TR) e3 DC to DC switching controller 5ns 4mA 800mum 800mV
PDF
/
Buying Options
Total Price: USD $5.75
Unit Price: USD $5.7464
≥1 USD $5.7464
≥10 USD $5.1612
≥100 USD $4.879424
≥500 USD $4.228928
Inventory: 1000
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 750μm
Width 4mm
Length 4mm
Height 800μm
Technical
Duty Cycle 99 %
Clock Sync No
Isolation Isolated
Max Frequency 530kHz
Fall Time (Typ) 5 ns
Synchronous Rectifier Yes
Rise Time 6 ns
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 65V
Frequency - Switching 200kHz 480kHz
Control Mode CURRENT-MODE
Min Input Voltage 5.5V
Topology Buck
Control Features Frequency Control, Ramp, Soft Start
Quiescent Current 4.8mA
Voltage - Supply (Vcc/Vdd) 5.5V~65V
Output Configuration Positive
Operating Supply Current 4mA
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 48V
Output Type Transistor Driver
Output Voltage 800mV
Number of Outputs 1
Function Step-Down
Base Part Number LM5117
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Subcategory Switching Regulator or Controllers
Additional Feature PROGRAMMABLE OUTPUT FROM 0.8V
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 24
Package / Case 24-WFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
