LM5116HJD
RoHS
RoHS compliant
RoHS compliantPackage 20-CDIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LM5116 Buck Tube ACTIVE (Last Updated: 5days ago) DC to DC switching controller 12ns 1.6mA 4.45mm 80V
PDF
/
Buying Options
Total Price: USD $178.9
Unit Price: USD $178.904
≥1 USD $178.904
≥10 USD $171.342846
≥100 USD $167.563246
Inventory: 43
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Package / Case 20-CDIP (0.300, 7.62mm)
Number of Pins 20
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Terminal Pitch 2.54mm
Base Part Number LM5116
Function Step-Down
Number of Outputs 1
Output Voltage 80V
Output Type Transistor Driver
Operating Supply Voltage 80V
Input Voltage-Nom 48V
Analog IC - Other Type SWITCHING CONTROLLER
Operating Supply Current 1.6mA
Output Configuration Positive
Output Current 10A
Voltage - Supply (Vcc/Vdd) 6V~80V
Quiescent Current 4.6mA
Control Features Enable, Frequency Control, Ramp, Soft Start
Input Voltage (Min) 6V
Topology Buck
Control Mode CURRENT-MODE
Frequency - Switching 200kHz 535kHz
Control Technique PULSE WIDTH MODULATION
Rise Time 18 ns
Synchronous Rectifier Yes
Fall Time (Typ) 12 ns
Switcher Configuration PUSH-PULL
Max Duty Cycle 50 %
Isolation Non-Isolated
Dimensions
Height 4.45mm
Length 25.65mm
Width 7.37mm
Thickness 3.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
