LM5032MTC
RoHS
/
Package 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LM5032 Forward Converter Tube e0 DC to DC switching controller 10ns 2.5A 5mm 100V
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.489
≥1 USD $2.489
≥10 USD $2.0425
≥100 USD $1.97885
≥500 USD $1.91425
≥1000 USD $1.8506
Inventory: 15188
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Frequency 670kHz
Base Part Number LM5032
Function Step-Up/Step-Down
Number of Outputs 2
Output Type Transistor Driver
Input Voltage-Nom 48V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Output Current 2.5A
Voltage - Supply (Vcc/Vdd) 13V~100V
Output Power 600W
Control Features Frequency Control, Soft Start
Input Voltage (Min) 13V
Topology Forward Converter
Control Mode CURRENT-MODE
Frequency - Switching 200kHz 600kHz
Input Voltage (Max) 100V
Control Technique PULSE WIDTH MODULATION
Rise Time 12ns
Synchronous Rectifier No
Fall Time (Typ) 10 ns
Switcher Configuration SINGLE
Max Duty Cycle 76 %
Clock Sync Yes
Dimensions
Height 900μm
Length 5mm
Width 4.4mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Alternative Model
