LM5026SDX
RoHS
/
Package 16-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LM5026 Forward Converter Tape & Reel (TR) e0 DC to DC switching controller 15ns 3A 5mm 7.6V
PDF
/
Buying Options
Total Price: USD $6.72
Unit Price: USD $6.715617
≥1 USD $6.715617
≥10 USD $6.335497
≥100 USD $5.976881
≥500 USD $5.638564
≥1000 USD $5.319406
Inventory: 998
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Output Phases 1
Clock Sync Yes
Duty Cycle (Max) 70%, 80%
Max Duty Cycle 80 %
Max Frequency 1MHz
Switcher Configuration SINGLE
Fall Time (Typ) 15 ns
Synchronous Rectifier No
Rise Time 20ns
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 200kHz~590kHz
Control Mode CURRENT-MODE
Topology Forward Converter
Control Features Dead Time Control, Frequency Control, Reset, Soft Start
Voltage - Supply (Vcc/Vdd) 8V~15V
Output Current 3A
Output Configuration Positive, Isolation Capable
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 48V
Output Type Transistor Driver
Output Voltage 7.6V
Number of Outputs 2
Function Step-Up/Step-Down
Base Part Number LM5026
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Subcategory Switching Regulator or Controllers
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 16
Package / Case 16-WFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
