HPA00448PWP

Texas Instruments
RoHS
RoHS RoHS compliant
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description VOLTAGE-MODE DUAL ROHS3Compliant BUCK DC to DC switching controller 85C 1000kHz 55V 1.2mm
PDF
/
Inventory: 3175
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Surface Mount YES
Number of Pins 16

Technical

JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number HPA00448
Input Voltage-Nom 24V
Temperature Grade INDUSTRIAL
Analog IC - Other Type SWITCHING CONTROLLER
Quiescent Current 1.5mA
Input Voltage (Min) 10V
Control Mode VOLTAGE-MODE
Input Voltage (Max) 55V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration BUCK
Switching Frequency-Max 1000kHz

Dimensions

Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
