L6712ADTR
RoHS
/
Package 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
L6712 Buck Tape & Reel (TR) e4 DC to DC switching controller 2A 17.9mm 3.3V 150kHz
PDF
/
Buying Options
Total Price: USD $5.28
Unit Price: USD $5.2763
≥1 USD $5.2763
≥10 USD $4.32915
≥100 USD $4.19425
≥500 USD $4.0584
≥1000 USD $3.9235
Inventory: 1408
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 28
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Switching Regulator or Controllers
Technology BCDMOS
Terminal Position DUAL
Terminal Form GULL WING
Frequency 165kHz
Base Part Number L6712
Function Step-Down
Number of Outputs 2
Output Voltage 3.3V
Output Type Transistor Driver
Operating Supply Voltage 13.2V
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Voltage - Supply (Vcc/Vdd) 7.5V~15V
Quiescent Current 10mA
Control Features Frequency Control, Phase Control, Power Good
Input Voltage (Min) 10.8V
Topology Buck
Control Mode CURRENT-MODE
Output Current-Max 2A
Frequency - Switching 150kHz
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Switcher Configuration PHASE-SHIFT
Max Duty Cycle 80 %
Clock Sync No
Dimensions
Length 17.9mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
