ISL6445IAZ-TK
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
Buck Tape & Reel (TR) e3 Positive DC to DC switching controller 0.4A 8.645mm 5.6V 1.4MHz
PDF
/
Buying Options
Total Price: USD $2.42
Unit Price: USD $2.42
≥1 USD $2.42
Inventory: 975
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.895mm
Length 8.645mm
Height Seated (Max) 1.75mm
Technical
Clock Sync No
Duty Cycle (Max) 73%
Switcher Configuration PHASE-SHIFT
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 1.4MHz
Output Current-Max 0.4A
Control Mode CURRENT-MODE
Topology Buck
Input Voltage (Min) 5.6V
Control Features Enable, Phase Control, Power Good, Soft Start
Voltage - Supply (Vcc/Vdd) 5.6V~24V
Output Configuration Positive
Analog IC - Other Type DUAL SWITCHING CONTROLLER
Input Voltage-Nom 12V
Output Type Transistor Driver
Qualification Status COMMERCIAL
Number of Outputs 2
Function Step-Down
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.635mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish MATTE TIN
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 24-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
