UC2843BNG
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
UC284*B Boost Flyback Tube e3 DC to DC switching controller 50ns 17mA 4.953mm 13.4V
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.8976
≥1 USD $0.8976
≥10 USD $0.79992
≥100 USD $0.759264
≥500 USD $0.583
≥1000 USD $0.515222
≥3000 USD $0.488118
Inventory: 287
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Technical
Operating Temperature -25°C~85°C TA
Packaging Tube
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 862mW
Technology BIPOLAR
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Terminal Pitch 2.54mm
Frequency 52kHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number UC284*B
Function Step-Up, Step-Up/Step-Down
Number of Outputs 1
Output Voltage 13.4V
Output Type Transistor Driver
Input Voltage-Nom 15V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Power Dissipation 1.25W
Output Current 200mA
Voltage - Supply (Vcc/Vdd) 7.6V~30V
Max Supply Current 17mA
Control Features Frequency Control
Topology Boost, Flyback
Control Mode CURRENT-MODE
Frequency - Switching Up to 500kHz
Input Voltage (Max) 25V
Halogen Free Halogen Free
Control Technique PULSE WIDTH MODULATION
Rise Time 50 ns
Synchronous Rectifier No
Fall Time (Typ) 50 ns
Switcher Configuration SINGLE
Max Duty Cycle 96 %
Input Bias Current -2μA
Dimensions
Height 4.953mm
Length 10.16mm
Width 7.112mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
