MC34067PG
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
MC34067 Flyback Tube e3 DC to DC switching controller 50ns 800muA 4.535924g 5.1V
PDF
/
Buying Options
Total Price: USD $2.17
Unit Price: USD $2.1679
≥1 USD $2.1679
≥10 USD $1.7784
≥100 USD $1.7233
≥500 USD $1.66725
≥1000 USD $1.61215
Inventory: 1463
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 6.85mm
Length 19.55mm
Height 3.43mm
Technical
Output Phases 1
Max Duty Cycle 25 %
Switcher Configuration PUSH-PULL
Fall Time (Typ) 50 ns
Synchronous Rectifier No
Rise Time 50 ns
Control Technique RESONANT CONTROL
Halogen Free Halogen Free
Frequency - Switching 2.05MHz
Control Mode VOLTAGE-MODE
Topology Flyback
Control Features Enable, Soft Start
Max Supply Current 800μA
Voltage - Supply (Vcc/Vdd) 8.6V~20V
Output Current 10mA
Power Dissipation 1.25W
Output Configuration Positive, Isolation Capable
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 12V
Output Type Transistor Driver
Output Voltage 5.1V
Number of Outputs 2
Function Step-Up/Step-Down
Base Part Number MC34067
Time@Peak Reflow Temperature-Max (s) 40
Frequency 525kHz
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BIPOLAR
Subcategory Switching Regulator or Controllers
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e3
Published 2007
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Weight 4.535924g
Number of Pins 16
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE, NOT REC (Last Updated: 1 day ago)
Factory Lead Time 9 Weeks
