TC105503ECTTR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
TC1055 Buck Tape & Reel (TR) e3 DC to DC switching controller 50muA 100mA 2.9mm 5V
PDF
/
Buying Options
Total Price: USD $9.4
Unit Price: USD $9.3974
≥1 USD $9.3974
≥10 USD $7.7102
≥100 USD $7.46985
≥500 USD $7.22855
≥1000 USD $6.9882
Inventory: 66
Minimum: 1
-
+
Technical Details
Technical
Packaging Tape & Reel (TR)
Published 2002
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature PFM CONTROL TECHNIQUE IS ALSO POSSIBLE
Subcategory Switching Regulator or Controllers
Terminal Position DUAL
Terminal Form GULL WING
Operating Temperature -40°C~85°C TA
Duty Cycle (Max) 100%
Max Frequency 345kHz
Switcher Configuration SINGLE
Synchronous Rectifier No
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 300kHz
Control Mode VOLTAGE-MODE
Topology Buck
Input Voltage (Min) 2.2V
Control Features Enable
Quiescent Current 50μA
Voltage - Supply (Vcc/Vdd) 2.2V~10V
Output Current 100mA
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Operating Supply Voltage 10V
Output Type Transistor Driver
Output Voltage 5V
Number of Outputs 1
Function Step-Down
Base Part Number TC1055
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 2.9mm
