HV9123P-G
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
HV9123 Flyback Tube e3 DC to DC switching controller 20ns 750muA 1.627801g 13.5V
PDF
/
Buying Options
Total Price: USD $4.2
Unit Price: USD $4.1976
≥1 USD $4.1976
≥10 USD $3.4936
≥100 USD $3.1768
Inventory: 210
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Number of Pins 16
Weight 1.627801g
Technical
Operating Temperature -55°C~125°C TJ
Packaging Tube
Published 2014
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Terminal Position DUAL
Supply Voltage 10V
Terminal Pitch 2.54mm
Base Part Number HV9123
Function Step-Up/Step-Down
Number of Outputs 1
Output Voltage 13.5V
Output Type Transistor Driver
Operating Supply Voltage 13.5V
Input Voltage-Nom 48V
Analog IC - Other Type SWITCHING CONTROLLER
Operating Supply Current 750μA
Output Configuration Positive
Voltage - Supply (Vcc/Vdd) 10V~450V
Control Features Enable, Frequency Control, Reset
Input Voltage (Min) 9V
Topology Flyback
Control Mode CURRENT-MODE
Frequency - Switching 3MHz
Input Voltage (Max) 80V
Control Technique PULSE WIDTH MODULATION
Rise Time 30 ns
Synchronous Rectifier No
Fall Time (Typ) 20 ns
Switcher Configuration SINGLE
Max Duty Cycle 99 %
Duty Cycle (Max) 97%
Dimensions
Height Seated (Max) 5.334mm
Length 20.066mm
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
