MAX770ESA+T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
MAX770 Boost Tape & Reel (TR) e3 DC to DC switching controller 1A 4.9mm 3V 300kHz
PDF
/
Buying Options
Total Price: USD $5.92
Unit Price: USD $5.921924
≥1 USD $5.921924
≥10 USD $5.586719
≥100 USD $5.270491
≥500 USD $4.972162
≥1000 USD $4.690719
Inventory: 1100
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Duty Cycle 90 %
Max Frequency 300kHz
Synchronous Rectifier No
Control Technique PULSE FREQUENCY MODULATION
Control Mode CURRENT-MODE
Topology Boost
Input Voltage (Min) 2V
Control Features Enable
Voltage - Supply (Vcc/Vdd) 3V~16.5V
Output Current 1A
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 5V
Output Type Transistor Driver
Output Voltage 3V
Number of Outputs 1
Function Step-Up
Base Part Number MAX770
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Switching Regulator or Controllers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e3
Published 1997
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
