MAX5094AASA
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
VOLTAGE-MODE BICMOS DUAL Surface Mount DC-DC Controller IC -40C~125C TJ 20kHz~1MHz 25V 4.9mm
PDF
/
Buying Options
Total Price: USD $1.84
Unit Price: USD $1.843
≥1 USD $1.843
≥10 USD $1.5124
≥100 USD $1.4649
≥500 USD $1.4174
≥1000 USD $1.37085
Inventory: 1174
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Duty Cycle (Max) 96%
Switcher Configuration SINGLE
Synchronous Rectifier No
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 25V
Frequency - Switching 20kHz~1MHz
Output Current-Max 1A
Control Mode VOLTAGE-MODE
Topology Flyback, Forward Converter
Control Features Frequency Control
Voltage - Supply (Vcc/Vdd) 7.6V~30V
Output Configuration Positive, Isolation Capable
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 15V
Output Type Transistor Driver
Number of Outputs 1
Function Step-Up/Step-Down
JESD-30 Code R-PDSO-G8
Base Part Number MAX5094
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Switching Regulator or Controllers
Additional Feature IT CAN ALSO OPERATE WITH CURRENT MODE
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2006
Packaging Tube
Operating Temperature -40°C~125°C TJ
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
