MAX5038AEAI25
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
MAX5038 Buck Tube e0 DC to DC switching controller 4A 1.99mm 2.5V 250kHz 500kHz
PDF
/
Inventory: 6987
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SSOP (0.209, 5.30mm Width)
Number of Pins 28
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2016
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn85Pb15)
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Terminal Pitch 0.65mm
Base Part Number MAX5038
Function Step-Down
Number of Outputs 2
Output Voltage 2.5V
Output Type Transistor Driver
Operating Supply Voltage 28V
Input Voltage-Nom 5V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Output Current 4A
Voltage - Supply (Vcc/Vdd) 4.75V~28V
Control Features Enable
Input Voltage (Min) 4.75V
Topology Buck
Control Mode CURRENT-MODE
Frequency - Switching 250kHz 500kHz
Input Voltage (Max) 5.5V
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Switcher Configuration PHASE-SHIFT
Clock Sync No
Dimensions
Height Seated (Max) 1.99mm
Compliance
RoHS Status ROHS3 Compliant
