MAX1715EEI
RoHS
/
Package 28-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
CURRENT-MODE DUAL Surface Mount Non-RoHS Compliant DC-DC Controller IC 640mW -40C~85C TA 200kHz 300kHz 420kHz 540kHz 5.5V
PDF
/
Buying Options
Total Price: USD $2.07
Unit Price: USD $2.07385
≥1 USD $2.07385
≥10 USD $1.7024
≥100 USD $1.6492
≥500 USD $1.596
≥1000 USD $1.5428
Inventory: 17196
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-SSOP (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2005
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Subcategory Switching Regulator or Controllers
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Terminal Pitch 0.635mm
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number MAX1715
Function Step-Down
Number of Outputs 2
Output Type Transistor Driver
Input Voltage-Nom 5V
Analog IC - Other Type DUAL SWITCHING CONTROLLER
Output Configuration Positive
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
Output Power 640mW
Control Features Current Limit, Enable, On Time Control, Power Good
Input Voltage (Min) 4.5V
Topology Buck
Control Mode CURRENT-MODE
Frequency - Switching 200kHz 300kHz 420kHz 540kHz
Input Voltage (Max) 5.5V
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Switcher Configuration PUSH-PULL
Duty Cycle (Max) 100%
Clock Sync No
Output Phases 1
Dimensions
Length 9.89mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
