LTC7800EUDC#PBF
RoHS
RoHS compliant
RoHS compliantPackage 20-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LTC7800 Buck Tube Positive DC to DC switching controller 4V~60V 320kHz~2.25MHz -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $6.17
Unit Price: USD $6.1688
≥1 USD $6.1688
≥10 USD $5.5748
≥100 USD $4.615362
≥500 USD $4.565009
Inventory: 1148
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Duty Cycle (Max) 98%
Synchronous Rectifier No
Frequency - Switching 320kHz~2.25MHz
Topology Buck
Control Features Current Limit, Power Good, Soft Start, Tracking
Voltage - Supply (Vcc/Vdd) 4V~60V
Output Configuration Positive
Output Type Transistor Driver
Number of Outputs 1
Function Step-Down
Base Part Number LTC7800
Reach Compliance Code compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2013
Packaging Tube
Operating Temperature -40°C~125°C TJ
Physical
Package / Case 20-WFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
