LTC3807EFE#PBF image
Favorite
LTC3807EFE#PBF image
Favorite
RoHS
RoHS RoHS compliant
Package 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description Surface Mount ROHS3Compliant Transistor Driver 2014 DC-DC Controller IC -40C~125C TJ 50kHz~900kHz 4V~38V
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width) Exposed Pad

Technical

Operating Temperature -40°C~125°C TJ
Packaging Tube
Published 2014
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Base Part Number LTC3807
Function Step-Down
Number of Outputs 1
Output Type Transistor Driver
Output Configuration Positive
Voltage - Supply (Vcc/Vdd) 4V~38V
Control Features Current Limit, Enable, Frequency Control, Soft Start, Tracking
Topology Buck
Frequency - Switching 50kHz~900kHz
Synchronous Rectifier Yes
Duty Cycle (Max) 99%
Clock Sync No

Compliance

RoHS Status ROHS3 Compliant
