LTC3786HUD#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 16-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LTC3786 Boost Flyback SEPIC Tape & Reel (TR) OPERATES IN ADJUSTABLE MODE DOWN TO 60V DC to DC switching controller 3mm 38V 105kHz~760kHz -40C~150C TJ
PDF
/
Buying Options
Total Price: USD $5.23
Unit Price: USD $5.231907
≥1 USD $5.231907
≥200 USD $2.024492
≥500 USD $1.953595
≥1000 USD $1.91946
Inventory: 1264
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-WFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Additional Feature OPERATES IN ADJUSTABLE MODE DOWN TO 60V
Technology CMOS
Terminal Position QUAD
Terminal Pitch 0.5mm
Base Part Number LTC3786
Function Step-Up, Step-Up/Step-Down
Number of Outputs 1
Output Type Transistor Driver
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Voltage - Supply (Vcc/Vdd) 4.5V~38V
Control Features Current Limit, Enable, Frequency Control, Power Good, Soft Start
Input Voltage (Min) 4.5V
Topology Boost, Flyback, SEPIC
Control Mode CURRENT-MODE
Frequency - Switching 105kHz~760kHz
Input Voltage (Max) 38V
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Duty Cycle (Max) 96%
Clock Sync No
Dimensions
Height Seated (Max) 0.8mm
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
