LTC1735EGN#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LTC1735 Buck Tube e3 DC to DC switching controller 50ns 3kA 4.9mm 6V
PDF
/
Buying Options
Total Price: USD $9.67
Unit Price: USD $9.6712
≥1 USD $9.6712
≥10 USD $8.88536
≥100 USD $8.517344
Inventory: 88
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Clock Sync No
Duty Cycle (Max) 99.4%
Max Frequency 335kHz
Switcher Configuration PUSH-PULL
Fall Time (Typ) 50 ns
Synchronous Rectifier Yes
Rise Time 50ns
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 300kHz
Control Mode CURRENT-MODE
Topology Buck
Input Voltage (Min) 3.5V
Control Features Enable, Power Good, Soft Start
Voltage - Supply (Vcc/Vdd) 4V~30V
Output Current 3kA
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 15V
Output Type Transistor Driver
Output Voltage 6V
Number of Outputs 1
Function Step-Down
Base Part Number LTC1735
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.635mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Switching Regulator or Controllers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 4 weeks ago)
Factory Lead Time 8 Weeks
