LT3758IDD#PBF
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LT3758 Boost Flyback SEPIC Tube e3 DC to DC switching controller 3mm 100V 100kHz~1MHz -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $6.45
Unit Price: USD $6.4504
≥1 USD $6.4504
≥10 USD $5.82824
≥100 USD $5.557376
≥500 USD $4.825313
≥1000 USD $4.608437
≥3000 USD $4.201806
Inventory: 855
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
Clock Sync Yes
Max Frequency 1MHz
Synchronous Rectifier No
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 100kHz~1MHz
Control Mode CURRENT-MODE
Topology Boost, Flyback, SEPIC
Input Voltage (Min) 5.5V
Control Features Enable, Frequency Control, Soft Start
Voltage - Supply (Vcc/Vdd) 5.5V~100V
Output Configuration Positive or Negative, Isolation Capable
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 24V
Output Type Transistor Driver
Output Voltage 100V
Number of Outputs 1
Function Step-Up, Step-Up/Step-Down
Base Part Number LT3758
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BIPOLAR
Subcategory Switching Regulator or Controllers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2010
Packaging Tube
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 10
Package / Case 10-WFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 months ago)
Factory Lead Time 8 Weeks
