LT3724EFE#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LT3724 Buck Boost SEPIC Tube e3 DC to DC switching controller 0.3A 5mm 8V 200kHz
PDF
/
Buying Options
Total Price: USD $7.97
Unit Price: USD $7.9728
≥1 USD $7.9728
≥10 USD $7.20456
≥100 USD $5.964358
≥500 USD $5.696319
≥1000 USD $5.193698
≥3000 USD $4.523543
Inventory: 1139
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 5mm
Technical
Switcher Configuration SINGLE
Synchronous Rectifier No
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 60V
Frequency - Switching 200kHz
Output Current-Max 0.3A
Control Mode CURRENT-MODE
Topology Buck, Boost, SEPIC
Input Voltage (Min) 4V
Control Features Enable, Soft Start
Voltage - Supply (Vcc/Vdd) 4V~60V
Output Configuration Positive or Negative
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 20V
Output Type Transistor Driver
Output Voltage 8V
Number of Outputs 1
Function Step-Up, Step-Down, Step-Up/Step-Down
Base Part Number LT3724
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Switching Regulator or Controllers
Additional Feature ALSO OPERATES IN ADJUSTABLE OUTPUT AVAILABLE UPTO 36V
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2011
Packaging Tube
Operating Temperature -40°C~125°C TJ
Physical
Surface Mount YES
Package / Case 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
