LT1680CN#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LT1680 Boost Forward Converter Tube e3 DC to DC switching controller 12mA 10A 3.937mm 60V
PDF
/
Buying Options
Total Price: USD $10.56
Unit Price: USD $10.56
≥1 USD $10.56
≥10 USD $9.70904
≥100 USD $9.306528
≥500 USD $8.199928
≥1000 USD $7.797434
≥3000 USD $7.29439
Inventory: 796
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Physical
Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 16
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 2001
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Switching Regulator or Controllers
Technology BIPOLAR
Terminal Position DUAL
Terminal Pitch 2.54mm
Base Part Number LT1680
Function Step-Up, Step-Up/Step-Down
Number of Outputs 1
Output Voltage 60V
Output Type Transistor Driver
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Output Current 10A
Voltage - Supply (Vcc/Vdd) 9V~60V
Quiescent Current 12mA
Control Features Enable, Soft Start
Topology Boost, Forward Converter
Control Mode CURRENT-MODE
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier No
Switcher Configuration SINGLE
Max Frequency 200kHz
Duty Cycle (Max) 90%
Clock Sync Yes
Dimensions
Height Seated (Max) 3.937mm
Width 7.62mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
