UCC391PW
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Contains Lead GULL WING ROHS3Compliant Series Voltage Reference IC 4.4mm ±0.39% 0C~70C TA 5.5V
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.4696
≥1 USD $1.4696
Inventory: 6722
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 4.4mm
Technical
Reference Type Series
Voltage - Output (Min/Fixed) 1.3V
Current - Supply 1.8mA
Quiescent Current 1.8mA
Current - Output 150μA
Voltage - Input 4.5V~8V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Output Type Adjustable
Output Voltage 3.5V
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 8
Base Part Number UCC391
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Voltage References
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
Tolerance ±0.39%
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 8
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
