UC39431N
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Through Hole Contains Lead ROHS3Compliant DUAL Shunt Voltage Reference IC 528.605208mg ±0.39% 0C~70C TA 36V
PDF
/
Buying Options
Total Price: USD $5.9
Unit Price: USD $5.896
≥1 USD $5.896
Inventory: 115
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 8
Weight 528.605208mg
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Tolerance ±0.39%
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Number of Functions 1
Supply Voltage 15V
Terminal Pitch 2.54mm
Base Part Number UC39431
Pin Count 8
Number of Outputs 1
Output Voltage 36V
Output Type Adjustable
Max Output Current 100mA
Supply Voltage-Min (Vsup) 2.2V
Number of Channels 1
Trim/Adjustable Output NO
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Nominal Supply Current 500μA
Current - Output 100mA
Quiescent Current 800μA
Max Output Voltage 36V
Max Input Voltage 36V
Reference Type Shunt
Min Output Voltage 1.3V
Dimensions
Height 4.57mm
Length 9.81mm
Width 6.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
