TLVH431ACDBZT
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 TLVH431 Tape & Reel (TR) ACTIVE (Last Updated: 5days ago) voltage reference device 100muA 20V 0C~70C TA ±1%
PDF
/
Buying Options
Total Price: USD $0.82
Unit Price: USD $0.8184
≥1 USD $0.8184
≥10 USD $0.73216
≥100 USD $0.694496
≥500 USD $0.570504
Inventory: 1161
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1mm
Width 1.3mm
Length 2.92mm
Height 1.22mm
Technical
Current - Cathode 100μA
Min Output Voltage 1.24V
Reference Type Shunt
Reference Voltage 18V
Max Input Voltage 20V
Min Input Voltage 1.24V
Max Output Voltage 18V
Current - Output 70mA
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Max Output Current 80mA
Output Type Adjustable
Output Voltage 18V
Number of Outputs 1
Pin Count 3
Base Part Number TLVH431
Terminal Pitch 0.95mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Voltage References
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 129 ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Tolerance ±1%
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 3
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
