TLV431AILPE3
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 TLV431 Bulk ACTIVE (Last Updated: 1week ago) voltage reference device 80muA 6V -40C~85C TA ±1%
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.0296
≥1 USD $1.0296
≥10 USD $0.92048
≥100 USD $0.873664
≥500 USD $0.717552
≥1000 USD $0.670736
≥3000 USD $0.592733
Inventory: 1138
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 3.6mm
Width 4.3mm
Length 4.3mm
Height 5.34mm
Technical
Current - Cathode 80μA
Min Output Voltage 1.24V
Reference Type Shunt
Reference Voltage 6V
Max Input Voltage 7V
Max Output Voltage 6V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Supply Voltage-Max (Vsup) 6V
Max Output Current 15mA
Output Type Adjustable
Output Voltage 6V
Number of Outputs 1
Pin Count 3
Base Part Number TLV431
Number of Functions 1
Terminal Position BOTTOM
Technology BIPOLAR
Terminal Finish Matte Tin (Sn)
Temperature Coefficient 39 ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±1%
Packaging Bulk
Operating Temperature -40°C~85°C TA
Physical
Weight 213.188414mg
Number of Pins 3
Surface Mount NO
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
