TL432ACDBVR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Lead Free GULL WING ROHS3Compliant Shunt Voltage Reference IC 15.790684mg ±1% 92ppm/C 37V
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3256
≥1 USD $0.3256
≥10 USD $0.26752
≥100 USD $0.24464
≥500 USD $0.181984
≥1000 USD $0.164947
≥3000 USD $0.136523
Inventory: 5959
Minimum: 1
-
+
Technical Details
Technical
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TL432
Pin Count 5
Number of Outputs 1
Output Voltage 36V
Output Type Adjustable
Max Output Current 100mA
Number of Channels 1
Trim/Adjustable Output YES
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Max Output Voltage 36V
Voltage - Output (Min/Fixed) 2.495V
Max Input Voltage 37V
Reference Type Shunt
Temp Coef of Voltage-Max 92 ppm/°C
Current - Cathode 600μA
Subcategory Voltage References
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 34 ppm/°C
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Tolerance ±1%
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 15.790684mg
Number of Pins 5
Surface Mount YES
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
